Visualization with the
display system
300
1SVC 440 795 M1100
If you wish to display the value range from 0 to 120 seconds,
for example, from a timing relay in minutes (0 to 2 min),
enter 0 as the minimum value and 120 as maximum value in
the Value range area. Enter “min” as a unit of measure.
Activate the Scaling range area and enter 0 as the minimum
value and 2 as the maximum value.
Programming in CL-SOFT:
X Drag the Value entry element onto the screen with the left
mouse button depressed.
X Position the cursor over the screen element and move it to
the required position whilst holding down the left mouse
button.
The height of the screen frame depends on the font size.
Three sizes are possible:
• Normal font,
•Double font size and
• Fourfold font size
The font size can be changed in the context menu (right
click) or by dragging the selection square at the bottom of
the element frame. To increase the font size, sufficient space
must be available underneath the element.
The width of the screen element frame can be scaled as
required by dragging the selection squares on the side.
“Set Variable” tab
In the Set variable tab you enter the Boolean variable for
which you wish to set the value.
“Number range/format” tab
You define the following on the Number range/format tab:
• Value range,
• Unit of measure,
• Scaling range and
• Input format.
The display of the sign can be forced.
