ABB CL Series User Manual

Visualization with the
display system
304
1SVC 440 795 M1100
Screen 5:
Screen 5 shows an example using the Visibility tab. If I4 is
closed, the value entry element is made invisible. The N/O
contact bit logic is set. If N/C contact bit logic was set, this
would create a visible switch function. The element remains
operable even when invisible, and value entry is still
possible.
Figure: 168: Switch value entry element invisible
Screen 6:
Screen 6 shows an example using the Operability tab. The
same Visibility setting is used as in screen 5. Closing I3 will
disable the entry function (N/O contact bit logic). If the value
entry element is disabled, you can still select it (it flashes),
but Entry mode (change values) is disabled. If the value entry
element is in Entry mode when I3 is closed, the display
system switches automatically to Selection mode. If N/C
contact is set as bit logic, entry is only possible if I3 is
actuated. I4 switches the value entry element to invisible,
however, it still remains operable allowing values to be
changed.
Figure: 169: Value entry element disabled
Set value visible Set value invisible
I3 not actuated I3 actuated
Set value entry
invisible
QV via I4
299 1037
Set value entry
invisible
QV via I4
299
Set value entry
Blocked
QV via I3
249 1037
Set value entry
Blocked
QV via I3
249 1037
