ABB CL Series User Manual

Technical data
391
1SVC 440 795 M1100
[lb]
0.32
Mounting Fitted on the fixing shaft of the
display modules
or on the top-hat rail to
DIN 50022, 35 mm
(without display)
or by means of fixing brackets
(without display)
Display I/O module
CL-LDR…, CL-LDT…
Dimensions when fitted
W × H × D
[mm] 89 × 90 × 25
[inches] 3.5 × 3.54 × 0.98
Dimensions when removed
W × H × D
[mm] 89 × 90 × 44
[inches] 3.5 × 3.54 × 1.73
Weight
CL-LDR…; CL-LDT… [g] 150; 140
CL-LDR…; CL-LDT… [lb] 0.33; 0.31
Mounting Snap-fitted into the display base
module
Display base module
CL-LDC.L…

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
