ABB CL Series User Manual

List of function blocks
411
1SVC 440 795 M1100
Function block contacts
Contact Meaning of abbreviation Description
CY carry Status 1, if the value range is exceeded; (carry)
E1 error 1 Error 1, dependent on function block
E2 error 2 Error 2, dependent on function block
E3 error 3 Error 3, dependent on function block
EQ equal Comparison result, status 1 if values equal.
FB fall below Status 1, if the actual value is less than or equal to
the lower setpoint value;
GT greater than Status 1 if the value at I1 > I2;
LI limit indicator Value range manipulated variable exceeded
LT less than Status 1 if the value at I1 < I2;
OF overflow Status 1, if the actual value is greater than or equal
to the upper setpoint value;
Q1 output (Q1) Switch output
QV output value Current actual value of the function block
(e.g. counter value);
ZE zero Status 1, if the value of the element input QV is
equal to zero;
