Connecting the serial interface
75
1SVC 440 795 M1100
Figure: 59: Connection plug
a
h
It must be ensured in all circumstances that the connector
with the marking POW-Side is fitted in the interface of the
display base module. The serial interface only functions if
the display base module is providing the power feed
required for the interface cable.
