ABB CL Series User Manual

Commissioning
82
1SVC 440 795 M1100
In the following example, the display system carries out all
the wiring and performs the tasks of the circuit diagram
shown below.
Figure: 64: Lamp controller with display system
H1
L01–
S1 S2
L01+
L01–
F1
I 01----I 02- --Ä Q 01
+24V 0V 0V
I1 I3I2
Q1
12
DEL
ESC
ALT
OK
*
