4. On the Internet Connection page, choose Connect using Dialup modem.
5. On the Connection Name page, enter the connection name, for example, SPC remote
connection.
6. On the Phone Number to Dial page, enter the phone number of the PSTN line connected to the
PSTN modem.
7. On the Connection Availability page, choose whether this connection is available to all users.
8. On the Internet Account Information page, enter the following details:
- Username: SPC
- Password: password (default)
- Confirm Password: password
The Completing the New Connection Wizard page is displayed.
9. Click Finish to save the Dial-up connection to the PC.
Default code should be changed and noted accordingly as Vanderbilt is unable to retrieve this new
code. Forgotten codes are be remedied only by a factory default of the system, rendering loss of
programming. Programming can be restored if a backup is available.
To activate this dial-up connection:
l
Click the icon located in the Control Panel > Network Connections page.
The PC makes a data call to the PSTN line connected to the SPC PSTN module.
The SPC PSTN module answers the incoming data call after the designated number of rings and
establishes an IP link with the remote computer.
The SPC system automatically assigns an IP address to the remote PC.
For some Windows operating systems, a dialog box regarding Windows certification appears.
Vanderbilt deems it acceptable to continue. For further queries, contact your network administrator
or a Vanderbilt technician.
To obtain this IP address:
1. Right click the dial-up icon.
2. Click the Details tab.
The IP address is displayed as the Server IP address.
3. Enter this IP address in the address bar of the browser and click.
4. When the dial-up connection icon is displayed on the task bar of the PC, open the browser and
enter the IP address of the SPC.
The browser logon page is displayed.
SPC42/52/53/63 – Installation & Configuration Manual Accessing web server remotely
© Vanderbilt 2023 250 I-200572
08.12.2023
