Acre SPC42 - 21 Appendix; Network Cable Connections

21 Appendix
This appendix covers:
21.1 Network cable connections 264
21.2 Controller status LEDs 265
21.3 Powering expanders from the auxiliary power terminals 265
21.4 Calculating the battery power requirements 266
21.5 Domestic, Commercial and Financial mode default settings 267
21.6 SIA Codes 267
21.7 CID Codes 273
21.8 User PIN combinations 275
21.9 Duress PINs 275
21.10 Automatic inhibits 275
21.11 Wiring of mains cable to the controller 276
21.12 Maintenance controller 276
21.13 Maintenance 277
21.14 Zone types 278
21.15 Zone attributes 283
21.16 ATS levels and attenuation specifications 285
21.17 Supported card readers and card formats 286
21.18 FlexC Glossary 288
21.19 FlexC Commands 289
21.20 ATS Category Timings 292
21.21 ATP Category Timings 293
21.1 Network cable connections
A PC can be connected directly to the Ethernet interface of the SPCcontroller or via a LAN connection.
The tables below show the 2 possible connection configurations.
l
If the SPC is connected to an existing network via a hub, then connect a straight through cable
from the hub to the SPC and another from the hub to the PC.
l
If the controller is not connected to a network (that is, a hub or switch is not used), then a
crossover cable should be connected between the SPC controller and the PC.
Use the straight through cable for connecting the SPC controller to a PC via a hub.
