7 Controller hardware
This section describes the controller hardware.
See also
Powering expanders from the auxiliary power terminals on page265
Wiring the X-BUS interface on page35
Wiring an internal sounder on page48
Wiring the zone inputs on page45
Controller status LEDs on page265
7.1 Controller Hardware SPC42/SPC52/SPC53/SPC63
This section describes the controller for the SPC42, SPC43, SPC53, and SPC63 models.
The SPC controller provides 8 on-board wired zones and optional wireless zones.
Number Name Description
1 SPC status
LEDs
These LEDs display the status of various system parameters as described in
Controller status LEDs on page265.
