6253 DC Voltage Current Source/Monitor Operation Manual
4.2.2 Operations in Pulse Source Mode
4-12
Changing
the source
value
AUTO Source value
changing does
not induce range
changing.
Tp: Period time
Td: Measurement delay
time
Tds: Source delay time
Tw: Pulse width
Tm: Measurement time
(Integration time +
Measurement data
processing time)
Tcn: Operate processing time
Trc: Range change
processing time
HOLD
Changing
the source
value
AUTO Source value
changing
induces range
changing.
HOLD
Table 4-2 Operations in Pulse Source Mode (2 of 2)
Operational
condition
Trigger
mode
Description Operation Remarks
Source value change processing
(Not change the range)
Changes the source value
(Not change the range)
Base value
Source value
change processing
(Not change the
range)
Base value
Measurement trigger
Changes the source value
(Not change the range)
Changes the source value
(Change the range)
Base value
Base value
Changes the source value
(Change the range)
Measurement trigger
