6253 DC Voltage Current Source/Monitor Operation Manual
4.2.8 Source and Measurement Timing
4-55
The Auto Range Delay function is enabled only in the current measurement (IM) auto range.
It does not work in the fixed range or voltage measurement (VM).
The Auto Range Delay (Tar) is set as a value with respect to the 3 A range. For other ranges, the values
in 1/10 multiples are set, as shown in the table below.
• Tar (s) measure
Calculate the Tar setting using the expression below.
Tar = = 16666C
L
(Example) If CL = 1 F
Tar = 16666 1 F = 16.6 ms
Set Tar = 16.6 ms
Measurement
range
Setting value Example
3 A Tar 5000 ms
30 A Tar/10 500 ms
300 A Tar/100 50 ms
3 mA Tar/1000 5 ms
30 mA or
higher
00 ms
