6253 DC Voltage Current Source/Monitor Operation Manual
5.2 USB
5-4
5.2 USB
5.2.1 Overview
The 6253 is equipped with USB (Universal Serial Bus) conforming to USB 2.0 standard.
USB allows function settings and reading of measurement data with respect to multiple instruments
connected to the bus from a PC, making it simple to configure an automated measurement system.
NOTE: All operations using a PC or hub cannot be always guaranteed.
5.2.2 USB Specifications
• Standard: Complies with USB2.0 Full-Speed
• Connectors: USB type B (female)
• ID: USB ID, settable from 1 to 127
• Remote/Local: Available
• Input commands: Function setting and query with ASCII character string commands
• Output format: Measurement data and query response with ASCII character strings
• Driver: ADC instruments USB driver
5.2.3 Setting Up USB
5.2.3.1 Connecting with Personal Computer
Connect the USB connector (type B) on the rear of the 6253 to that on a personal computer with a cable.
Fully insert all connectors.
Use a USB hub to connect multiple instruments to a single personal computer.
To Next Page
