6253 DC Voltage Current Source/Monitor Operation Manual
5.3 GPIB
5-5
5.3 GPIB
5.3.1 Overview
GPIB (General Purpose Interface Bus) allows you to externally set the measurement functions and
parameters on the 6253 and read out the measured data, making it simple to configure an automated
measurement system.
As GPIB signals from the 6253 are electrically isolated inside the unit from the measurement signal
system, connecting external devices does not affect the measured values.
The remote commands are the same as with USB.
• General specifications
Standard: IEEE-488.2
Code: ASCII code
Logic level: Logical 0 “High” +2.4 V min.
Logical 1 “Low” +0.4 V max.
Table 5-1 Interface Function
Code Function
SH1 Source Handshake capability
AH1 Acceptor handshake capability
T6 Basic Talker, unaddressed if MLA, serial poll
L4 Basic Listener, unaddressed if MTA
SR1 Service Request capability
RL1 Remote/Local switching capability
PP0 No Parallel Poll capability
DC1 Device Clear capability (The SDC and DCL commands can be used.)
DT1 Device Trigger capability (The GET command can be used.)
C0 No Controller capability
E2 Using tri-state bus drivers
