6253 DC Voltage Current Source/Monitor Operation Manual
5.7.1 Normal Mode
5-24
2. Mantissa part and exponent part
The exponent columns below show exponents when scaling calculation is not performed.
Measurement function
Unit display
Decimal point and unit symbol form
Mantissa part Exponent part
DC voltage
measurement
Measurement
range
300 mV ddd.dddd E-03
3 V d.dddddd E+00
10 V dd.ddddd E+00
30 V dd.ddddd E+00
100 V ddd.dddd E+00
DC current
measurement
3 A d.dddddd E-06
30 A dd.ddddd E-06
300 A ddd.dddd E-06
3 mA d.dddddd E-03
30 mA dd.ddddd E-03
300 mA ddd.dddd E-03
2 A d.dddddd E+00
Resistance
measurement
Significant digits 1 digit 00000.0d E-09 to E+09
000000.d
000000d.
2 digits 00000.dd
00000d.d
00000dd.
3 digits 0000d.dd
0000dd.d
0000ddd.
4 digits 000d.ddd
000dd.dd
000ddd.d
5 digits 00d.dddd
00dd.ddd
00ddd.dd
6 digits 0d.ddddd
0dd.dddd
0ddd.ddd
