6253 DC Voltage Current Source/Monitor Operation Manual
5.7.1 Normal Mode
5-23
1. Header
The header is not output when the header setting is OFF.
• Main header
DV: DC voltage measurement
DI: DC current measurement
RM: DC voltage measurement/DC current measurement (resistance display)
EE: No data in the specified measurement memory
• Monitor main header
SV: DC voltage measurement
SI: DC current measurement
EE: No data in the specified measurement memory
• Sub header
Sub header
Main (monitor main) header
S: Oscillation Detection
U: High limit detected
B: Low limit detected
O: Range over
Z: For resistance measurement, the voltage source value is set to 0 (zero).
E: Calculation error (scaling function or total function)
H: The comparator calculation result is HI.
G: The comparator calculation result is GO.
L: The comparator calculation result is LO.
C: Scaling calculation data
N: NULL calculation data
: Others (space output)
High
Priority
Low
