6253 DC Voltage Current Source/Monitor Operation Manual
8.1 Source and Measurement
8-5
Output noise: For voltage source, within the range from no load to the maximum load
(Vp-p)
For current source, at the following load (Ap-p)
Voltage source
Current source
Range
Load
resistance
Low frequency noise
High frequency
noise
DC to 100 Hz DC to 10 kHz DC to 20 MHz
300 mV - 60 V300 V5 mV
3 V - 100 V400 V5 mV
10 V - 1 mV 3 mV 6 mV
30 V - 1 mV 3 mV 6 mV
100 V - 3 mV 5 mV 10 mV
Range
Load
resistance
Low frequency noise
High frequency
noise
DC to 100 Hz DC to 10 kHz DC to 20 MHz
3 A 10 kΩ 10 nA 60 nA 500 nA
30 A 10 kΩ 10 nA 60 nA 500 nA
300 A 10 kΩ 30 nA 150 nA 600 nA
3 mA 1 kΩ 200 nA 2 A6 A
30 mA 1 kΩ 2 A 15 A 20 A
300 mA 1 kΩ 20 A100 A 150 A
2 A 100 Ω 200 A 1 mA 1.5 mA
