6253 DC Voltage Current Source/Monitor Operation Manual
A-6
A.3 Execution Time
A.3.1 Remote Execution Time (Typical Value)
1. Measurement execution time
Conditions Source range: fixed
Measurement range: fixed, Trigger mode: external trigger,
Number of measurement digits: 6
1
/
2
digits
Integration time: 100 s, Measurement delay: 0.3 ms, Source delay: 30 s
Period: 2 ms, Pulse width: 1 ms
Header: OFF, Block delimiter: LF (DL1)
• Time from measurement by trigger input (*TRG) to completion of data output
• Time from measurement by source command reception and trigger input (*TRG) and to
completion of data output
In the DC or pulse source mode
• Time from measurement by spot command reception (measurement trigger execution after set-
ting the source value for the setting source function) to completion of data output
In the DC or pulse source mode
Source value condition USB GPIB LAN
DC or pulse source 5 ms 2 ms 2 ms
When the sweep start value is output 7 ms 5 ms 5 ms
When the sweep step value is output 5 ms 2 ms 2 ms
Source Command USB GPIB LAN
Vo l t a g e
source
SOV<data> (<data>: 1 character) 6 ms 5 ms 5 ms
Current
source
SOI<data> (No unit, <data>: 3 characters) 6 ms 5 ms 5 ms
Source Command USB GPIB LAN
Vo l t a g e
source
G<data> (<data>: 1 character) 6 ms 5 ms 5 ms
Current
source
G<data> (No unit, <data>: 3 characters) 6 ms 5 ms 5 ms
