2.6.2 Menu Structure and Parameter List
2-29
MENU
Category Edit (Input/Run level)Select
1) Compare SW Comparator calculation ON/OFF
OFF/ON
2) Scaling SW Scaling calculation ON/OFF
OFF/ON
3) Max/Min SW MAX/MIN calculation ON/OFF
OFF/ON
4) NULL SW NULL calculation ON/OFF
OFF/ON
5) Max/Min View Max/Min calculation result reading
Maximum Maximum measurement value
Minimum Minimum measurement value
Average Average measurement value
Total Total measurement value
Sample Count Number of calculated measurement data
1) High Value Comparator calculation upper limit value
0 to 999.9999Y *
2) Low Value Comparator calculation lower limit value
0 to 999.9999Y
3) Scaling Value A Scaling calculation constant A
0 to 999.9999Y However, “0” is unacceptable.
4) Scaling Value B Scaling calculation constant B
0 to 999.9999Y
5) Scaling Value C Scaling calculation constant C
0 to 999.9999Y
6) NULL Value NULL calculation constant
0 to 999.9999Y
Can be selected/changed only when NULL calculation is ON.
9) Const
8) Compute
*Y is prefix “yotta” that indicates 10
24
.
