MENU
Category Edit (Input/Run level)Select
1) OPR Signal INTERLOCK/OPERATE IN/OUT control signal function setting
Disable/Interlock/STBY IN/ OPR/SBY IN/ OPR/SUS IN/OPR OUT
2) Complete/Busy COMPLETE OUT/BUSY IN control signal function setting
Disable/MeasFront/Meas End/CMP HI/CMP GO/CMP LO/Busy In/
Busy Out/CMP HI or LO/Sweep End
3) TRIG IN External trigger input
Disable/Enable
4) Sig Width Control signal output pulse select
10 s / 100 s
1) Param Load Loading saved parameters
Load0 / Load1 / Load2 / Load3 / LoadDefault
Select one of these parameters above and press the ENTER key to run.
2) Param Save Saves the setting parameters.
Save0 / Save1 / Save2 / Save3 / SetDefaultAll
Select one of these parameters above and press the ENTER key to run.
11) Parameter
10) EXT Signal
To Next Page
