MENU
Category Edit (Input/Run level)Select
1) Limit Buzzer Limit detection buzzer
ON/OFF
2) Compare Buzzer Comparator calculation result buzzer
OFF/HI/GO/LO/HIorLO
3) Notice Buzzer Process completion notice buzzer
ON/OFF
4) Self Test Runs the selected self test.
Use the rotary knob to select
and the ENTER key to run.
1) Self Test: Self test execution
2) LCD Pattern Display: Display test
3) Key & Buzzer Test: Key and buzzer test
5) Relay Count Relay counter reading
*Viewing only and setting Not available
6) Serial No/REV Serial number and software revision reading
*Viewing only and setting Not available
7) LCD Off LCD display OFF
8) PON Load Parameter loading at power ON
Power Off/Load0
9) Error Log Error log reading
10) Compati Mode 6243-compatible mode
ON/OFF
13) System
1) Graph Displays the step numbers of the measurement data memory on the
horizontal axis and the measured values on the vertical axis.
2) Monitor-
Measure Graph
Displays the monitor value of the measurement data memory on the
horizontal axis and the measured values on the vertical axis.
14) Graph
To Next Page
