Figure 99: External router configuration
Soft key labeled “Auto” toggles between automatic and manual mode (while in automatic mode the router
availability is driven by the current data file, as programmed in Aesys® Verba 2014™ [1]).
In manual mode, the router availability can be forced (by hitting “On”) or disabled (by hitting “Off”), or
moving/clicking the slider shown in Figure 99.
Changes are saved by clicking “Ok”.
Be aware!
The control unit establishes a TCP-based connection while in external router mode (for getting rid of
UDP-related limitations enforced by some telecom operators while going 3G/4G) while makes use of a
communication protocol based on UDP while using the internal wireless adapter.
This fact implies that the control unit tries to connect to the central server UDP IP/port specified for Wi-
Fi connection in the latter case and tries to connect to the central server TCP IP/port specified for
GPRS while using the external router.
9.8.7 CMS
Aesys® TC-430™ is able to interoperate the Aesys® CMS for multimedia contents (Aesys® Creo™). The
configuration of the interface towards the CMS can be adjuisted by accessing “Setup
Interfaces setup
CMS”.
Note
The description of Aesys® Creo™ goes far beyond the scope of this document; please refer to Aesys®
customer service for more details about it.
9.8.7.1 Mode
The CMS can be configured for working in one of the following modes:
- Automatic: the URL of the CMS channel to download content from is provided by the data file (VDB)
currently loaded in the control unit;
