The digital tomosynthesis group contains X-ray modality settings to
control the X-ray system movement, the X-ray exposure parameters and
the image processing for the reconstruction.
1.
Radiographic parameters for acquisition
2.
Positioning controls for acquisition
3.
Recontruction parameters
4.
Dose adaptation for patient size
5.
Button to start the digital tomosynthesis workflow
Figure 44: Controls for digital tomosynthesis
WARNING:
The negative effect of movement on the quality of the
reconstruction sequence can be recuded by selecting the
narrower X-ray tube sweep angle.
The X-ray tube sweep angle can be set to 15 degrees or 22 degrees. If the
bodypart that is examined is likely to move (e.g. by breathing), a narrower
sweep angle is recommended, as its workflow has a shorter duration.
Below are recommended settings of SID and sweep angle for typical
examinations:
Table 6: Recommended settings of SID and sweep angle
SID Sweep angle
Chest 150 mm 15 degrees
Hand, foot 115 mm 22 degrees
DR 600 | Basic Workflow | 103
3261K EN 20210708 0808
