AGFA DR 600 - Cables, transducers and accessories

Cables, transducers and accessories
Cables, transducers and accessories which were tested and found to comply
with the collateral standard IEC60601-1-2 (EMC):
CAUTION:
Use of accessories, transducers and cables other than those
specified or provided by the manufacturer of this equipment
could result in increased electromagnetic emissions or
decreased electromagnetic immunity of this equipment and
result in improper operation.
Unless noted otherwise, available cable lengths are 16 m, 20 m and 24 m.
CR;
Gen/StC
type;
maximum length (m)
remark
Mini Console
10x AWG26;
30
20 m basic wiring + 10
m extension allowed
COM A
3 x AWG24 9p D-SUB
BU/BU;
20
Basic wiring / Attention
Cross Link
COM B
Standard RS-232 cable (9
Pin D-SUB);
20
Basic wiring
LAN Connectin to the
system
CAT 5e SF/UTP or F/
UTP;
20
Basic wiring
Positioning Control
Box without ME func-
tionality
4 x AWG20
20
Basic wiring
Light Push Button
2 x AWG20
Customized wiring
Exposer prep. / Ex-
poser
2 x AWG18
Customized wiring
System "ON"
2 x AWG18
Customized wiring
Door Contact
2 x AWG18
Customized wiring
