DR 600 Technical Data
Manufacturer
Agfa NV
Septestraat 27
2640 Mortsel, Belgium
Type 5530/100
Power line See Generator Technical Data
Stand-by power max. 3.3 A
Table movement
(full load of 320
kg)
max. 7.0 A
Permanent filtration
E7254FX X-ray
tube
2.8 mm Al @75kVp
(+ 0.2 mm Al with DAP meter integrated in the collima-
tor)
E7884X and
E7252X X-ray tube
2.9 mm Al @ 75kVp
(+ 0.2 mm Al with DAP meter integrated in the collima-
tor)
E7869XX X-ray
tube
3.1 mm Al @ 75kVp
(+ 0.2 mm Al with DAP meter integrated in the collima-
tor)
Environmental conditions
Table 44: Environmental conditions for the X-ray system
Environmental Conditions (during storage and transport)
Temperature (ambient) between -15° and 50° Celsius
Humidity (non condensing) between 15 and 90 % relative humidity
Atmospheric pressure between 70 and 106 kPa
Environmental Conditions (during normal operation)
Temperature (ambient) between 10° and 35° Celsius
DR 600 | Product Information | 281
3261K EN 20210708 0808
