Portable DR detector
When performing an exposure, keep in mind the following detector
orientation aids:
Table 3: Orientation aids
Tube side icon, indicating the side that faces the X-
ray tube
Patient orientation marker, red rectange printed at
the corner of the detector, for consistent orientation
relative to the patient
For an overview of the operation controls of the DR detector, refer to the user
manual of the DR detector.
The DR detector may come in contact with the patient.
Note: DR detectors that operate wireless contain an RF
transmitter. For detailed information, refer to the DR detector
user manual.
Related Links
Bucky on page 218
DR 600 | Introduction | 39
3261K EN 20210708 0808
