System messages
System messages are displayed at the bottom of the software console.
The color of the message indicates the importance:
Blue Information
Yellow Warning
Orange Error
Messages that require feedback from the user contain a button that can be
pressed.
Figure 75: Error message requiring user feedback
More than one message can be active. The number of active messages and the
type of messages is indicated on the navigation button.
Figure 76: Icon indicating that messages are waiting
178 | DR 600 | Software Console and Tube Head Display
3261K EN 20210708 0808
