Positioning the bucky
1. Press and hold the bucky lock switch.
The lock for the bucky movement is released.
2. Move the bucky in longitudinal direction.
Figure 89: Bucky lock switch
3. Release the bucky lock switch.
The position is locked.
4. To make sure the X-ray tube head and the bucky are aligned, use
automatic centering or check the centering icon on the tube head display.
Related Links
Automatically centering the X-ray tube head unit on page 171
DR 600 | Radiographic Table | 201
3261K EN 20210708 0808
