AGFA DR 600 - Radiographic Wall Stand

Radiographic Wall Stand
The radiographic wall stand allows vertical X-ray exposures of patients
standing or sitting in front of the radiographic wall stand.
The bucky has two variants, depending on the orientation for loading a
detector or cassette:
• Right hand side loading
• Left hand side loading
The wall stand bucky is height adjustable in a large range.
The wall stand has blue LED in the top that is lit when the radiographic wall
stand is selected as active workstation.
1
6
8
7
5
2
3
4
1.
Wall Stand column
2.
Active workstation indicator
3.
Bucky
4.
Button to switch on the collimator light
5.
Front panel
6.
Vertical movement handle
7.
Tilting extension
DR 600 | Radiographic Wall Stand | 209
3261K EN 20210708 0808
