Software Console and Tube Head Display
The software console is displayed on the NX workstation.
On a configuration with tube head display, the software console is displayed
on the tube head display as well. The arrangement and availability of the
controls may be different.
Table 7: Navigation
Navigation button Software console screen
Examination overview
Generator controls
X-ray modality controls
Positioning controls
Live camera image
Digital tomosynthesis controls
System messages
Topics:
• Action buttons
• Planned exposures
• Live camera image on the tube head display
• Image Preview Window
• Main screen of the Tube head display
• Device Status Frame
