Labeling of the bucky
Figure 28: (Sample of subtype
5523/120)
Figure 29: (Sample of subtype
5523/125)
The type label is located on the rear cov-
er of the bucky or on the bucky drawer
below the rotating platform.
The type label information for each
bucky model is available in the technical
data.
Class II equipment.
Pinch Points.
The label is positioned on the lateral
cover of the bucky or on the rotating
platform.
Maximum load capacity is 10 kg on the
bucky drawer when it is pulled out. Do
not lean or sit on the bucky.
The label is positioned on the lateral
cover of the bucky or on the rotating
platform.
Read the instructions in the user man-
ual.
The label is positioned on the lateral
cover of the bucky or on the rotating
platform.
Compliance with China RoHS SJ/
T11364-2006. Indication of the Environ-
ment Friendly Use Period (EFUP) as the
period (years) during which the hazard-
64 | DR 600 | Introduction
3261K EN 20210708 0808
