Automatic collimator technical data
Manufacturer Ralco
Via dei Tigli 13/G
20853 Biassono (MB), Italy
Supported type R 225 ACS
Maximum radiation leakage 150 kVp – 4 mA
Inherent filtration 2 mm Aluminum equivalent
Added filtration 0mm Al
2mm Al
1mm Al + 0.1mm Cu
1mm Al + 0.2mm Cu
Maximum field Size at SID of 100
cm
48 cm x 48 cm
Dimensions 28.5 cm x 24.4 cm x 20.2 cm (WxDxH)
Weight 11 kg
294 | DR 600 | Product Information
3261K EN 20210708 0808
