Labeling of the X-ray generator (Spellman)
Figure 32: Example of type label
Type label positioned on the left
side of the X-ray generator cabi-
net.
Generator type and rating: the
type label information for each
X-ray generator model is availa-
ble in the technical data.
Instruction label for keeping
free the venting slots, on the
top side of the X-ray generator
cabinet.
Fuses inside of the generator
All fuse types and ratings are listed in
chapter 8.3.2 Fuse Tables of the
technical manual 06220010
Fuses may be only replaced with
fuses of identical ratings.
Instruction label for replacing
fuses, inside the X-ray generator
cabinet.
Prohibition sign for dropping
fluids, on the top side of the X-
ray generator cabinet.
Label with electrical data, in-
side the X-ray generator cabinet
on the right side behind the up-
per electronic rack.
Label identifying the high volt-
age generator, inside the X-ray
generator cabinet, on the front
side of the high voltage genera-
tor.
