Wall Stand Technical Data
Manufacturer Agfa NV
Septestraat 27
2640 Mortsel, Belgium
Type
WS-Motorized-T-001 5522/600
Dimensions
Height 2245 mm
Width 610 mm (only front panel)
715 mm (with tilting handles)
825 mm (with patient hand grips)
Depth 640 mm
990 mm (with spacer)
Height of detector center 33.5 to 185 cm
Angle of the detector -20° to +90°
Minimum height of the bucky sur-
face in tilted (horizontal) position
72 cm
Distance between front panel and
detector
< 50 mm
Front panel attenuation equivalent
mm Aluminum
≤ 0.7
According to
DIN EN 60601-1-3 with 100kV and
HVL 3.6 mm Al
FDA 21 CFR § 1020.30 (n) with
100kV and HVL 3.6 mm Al
Weight
Radiographic wall stand 196 kg
Radiographic wall stand with spacer 205 kg
286 | DR 600 | Product Information
3261K EN 20210708 0808
