Additional Labeling of the Radiographic Wall Stand
Figure 27: Example of type
label
Type label on the rear side of the bucky.
The type label information for each combina-
tion of X-ray tube and X-ray generator is availa-
ble in the technical data.
This mark indicates that this is a Type B Equip-
ment
Functional earth
The bucky can be tilted to horizontal position.
Do not use the bucky as a seat.
The maximum load for the bucky movement in
vertical direction is 20 kg.
A pinch point label is located on top of the tilt-
ing extension.
Additional pinch point labels are located at the
top and at the bottom of the rail in the Wall
Stand column.
Related Links
Warning labels on the radiographic wall stand on page 58
Wall Stand Technical Data on page 286
