AGFA DR 600 - Remote Control for the X-Ray Tube Head Unit

Remote Control for the X-Ray Tube Head Unit
1
2
3
4
1.
Buttons for positioning the X-Ray Tube
2.
Buttons for collimator control
3.
Buttons for collimator light, tracking and automatic centering
4.
Indicators for battery charge level and yellow status indicator light
Figure 5: Remote Control the X-Ray Tube Head Unit
The remote control can be mounted on the wall using a holder. A typical
mounting position is near the radiographic wall stand.
Related Links
Positioning the X-Ray Tube using the Remote Control on page 186
Topics:
• Charging the battery of the remote control
• Remote control status indicator light
Charging the battery of the remote control
The remote control has a rechargeable battery. The battery charge level is
indicated on the remote control.
To charge the battery of the remote control:
Put the remote control in the charging unit.
DR 600 | Introduction | 25
3261K EN 20210708 0808
