AGFA DR 600 - Page 312

TP_T;
StC
type;
maximum length (m)
remark
Master ME/ES Signal
3 x AWG22;
20
Basic wiring
CAN Signal
Standard RS-232 cable
(9 Pin D-SUB);
20
Basic wiring / Extension
not allowed
Bucky D. exp. / Bucky se-
lect T
7 x AWG20;
20
Basic wiring
Float-GND
1x AWG12;
20
Basic wiring
230V Power Supply
3x AWG18;
20
Basic wiring
PE Cable
1x AWG10;
20
Basic wiring
AEC
CAT 5e SF/UTP or F/
UTP;
20
Basic wiring
Sync 1/2 Cable (Varian)
8 x AWG26;
16
Customized wiring /
PIN 9 NC
Image Data Line
Cable CR_PC_NIC - WS
Bucky (direct wire)
CAT6;
40
Customized wiring / di-
rect wire - Point to
Point / Extension not al-
lowed
TP_WS;
StC
type;
maximum length
(m)
remark
ME/ES Signal
2 x AWG22;
20
Basic wiring for DR 600 WS
Positioning Control
Box
4 x AWG20;
20
Basic wiring for DR400-600 WS
2 more Contorl Boxes can be
added in the system
