TP_WS;
StC
type;
maximum length
(m)
remark
CAN Signal
Standard RS-232
cable (9 Pin D-
SUB);
20
Basic wiring for DR 400-600
WS / Extension not allowed
X8 24V
2 x AWG16;
20
Basic wiring for DR 400-600
WS
Bucky D. exp.
6 x AWG20;
20
Basic wiring for DR 400-600
WS
230V Power Supply
3x AWG18;
20
Basic wiring for DR 400-600
WS
PE Cable
1x AWG10;
20
Basic wiring for DR 400-600
WS
AEC
CAT 5e SF/UTP or
F/UTP;
20
Basic wiring for DR 400-600
WS
Sync 3/4 Cable (Var-
ian)
8 x AWG26;
20
Customized wiring / PIN 9 NC
Image Data Line
Cable CR_PC_NIC -
WS Bucky (direct
wire)
CAT6;
40
Customized wiring / direct wire
- Point to Point / Extension not
allowed
CS;
StC
type;
maximum length (m)
remark
ME/ES Signal
4 x AWG22;
20
Basic wiring
CAN Signal
3 x AWG22;
20
Basic wiring / Extension
not allowed
Float-GND
1x AWG12;
20
Basic wiring
