Which ASM capillary shall be used depends on the ASM factor, which is optimum
for your application. You may choose from following capillaries:
Port Number of
Capillary
Connection L x ID [mm] P/N Description
1 11 waste line self-cut x 0.7 0890-1713 Tubing-flexible 0.8/1.61mm
PTFE WT (delivered with UV
detector)
2 6b transfer capillary to MHC Valve (IN), deck A 170 x 0.12 5500-1376 Capillary ST 0.12x170 M/M
3 6b transfer capillary from MHC Valve (OUT),
deck B
170 x 0.12 5500-1376 Capillary ST 0.12x170 M/M
45 F3
from pressure release kit; from
1
D column,
1
D detector
105 x 0.17
500 x 0.12
5500-1240
5500-1157
Capillary ST 0.17x105 SL/SL
Capillary ST 0.12x500 SL/S
59
from
2
D pump
280 x 0.17 5067-4608 Capillary ST 0.17x280 SX/S
6 ASM1-4 outlet to ASM capillary L x 0.12 see list below
7 6b transfer capillary to MHC Valve (IN), deck B 170 x 0.12 5500-1376 Capillary ST 0.12x170 M/M
8 6b transfer capillary from MHC Valve (OUT),
deck A
170 x 0.12 5500-1376 Capillary ST 0.12x170 M/M
9 ASM1-4 inlet from ASM capillary L x 0.12 see list below
10 7
to
2
D column
400 x 0.12 5500-1251 Capillary ST 0.12x400 SL/SL
Capillary p/n Length (mm) Inner diameter
(mm)
Volume
(µl)
ASM factor Split ratio
(loop:ASM)
5500-1300 85 0.12 0.96 5 1:4
5500-1301 170 0.12 1.9 3 1:2
5500-1302 340 0.12 3.8 2 1:1
5500-1303 680 0.12 7.7 1.5 1:0.5
