4Installation
Hardware Installation
2D-LC User Guide 86
Install the Valve Head and Connecting Capillaries
For instructions on how to install the valve head and connecting capillaries, see
“Replace Valve Heads (G1170A)” on page 327.
3 Insert the pressure release assembly to the leak tray,
orientation as shown.
4 Push the pressure release assembly in the correct
position.
5 Connect with the T-piece, see Figure 41 on page 85.
to waste
to T-piece (inline with the detector)
To Next Page
