Special Topics
Performing cool on-column injection onto 250-µm and 320-µm columns
163
3. Push the assembly gently down into place. Make sure the slide lies flat on
syringe carriage so that it glides up and down the tracks as shown in the
illustration below.
Figure 82. Cross-section of slide alignment
Installing the syringe into the needle support assembly
Use the following steps to install a new syringe:
1. If you have removed the injector module to install the needle support
assembly, place the module back on the GC oven or on a parking post if
you have one.
2. Open the injector door.
Bearing
Guide
Slide
Tracks
Slide
Tracks
Syringe latch
