Preparing for Operation
Preparing the solvent and waste bottles
39
• If a tray is not installed, place two or three bottles (solvent A, waste A, and
solvent B) in the turret positions. Position 3 in the turret can be used as
sample 3 or solvent B. Make sure you have the correct vial in the turret.
Figure 30. Examples with and without a tray
Top view with a tray Top view without a tray
Solvent A Solvent A
Solvent B
Waste B
Waste A Waste A
Solvent B
