Chapter 4 267
Key Function Descriptions
Key Descriptions
Front-panel key access: CONFIG
PRINTER CONFIG Accesses printer configuration options to set the
printer address and to select a black-and-white or color
printer.
Front-panel key access:
CONFIG
NOTE If the printer is not connected when any of the print functions are
executed, then the message CONNECT PRINTER appears in the active
function block.
PURGE CORR Allows you to delete the entire table of
frequency-amplitude correction points currently being
edited.
Front-panel key access:
CAL
PWR MENU HELP Includes measurement information for making
occupied power bandwidth, channel power, carrier
power, and adjacent channel power measurements.
Front-panel key access:
MEAS/USER
PWR ON STATE Saves the current instrument state in the power-on
register. The spectrum analyzer is then set to this state
whenever
LINE is switched on. The same state can be
retrieved with POWER ON, available from the
RECALL
menu.
Front-panel key access:
SAVE
PWR SWP ON OFF For 8560E/EC Option 002. Activates (ON) or
deactivates (OFF) the power-sweep function, where the
output power of the tracking generator is swept over
the power-sweep range chosen. The value of the
power-sweep range is displayed in the active function
block, when PWR SWP ON OFF is turned on. The
power-sweep range can be set from 0 to 12.8 dB;
however, the power-sweep range specified under
warranty is 10 dB. It can be adjusted using the data
keys, step keys, or knob.
The output power of the tracking generator is swept
according to the sweep rate of the spectrum analyzer.
Power-sweep measurements are particularly useful in
making gain compression or output power versus
frequency measurements.
Front-panel key access:
AUX CTRL
