Agilent Technologies 8563E User Manual

38 Chapter1
Quick Start Guide
Front Panel Overview
Table 1-2
Connector Frequency Range Amplitude/ Voltage
Limits
INPUT 50 Ω 8560E/EC:
30 Hz–2.9 GHz (dc coupled)
100 kHz–2.9 GHz (ac coupled)
8561E/EC:
30 Hz–6.5 GHz (dc coupled)
100 kHz–6.5 GHz (ac coupled)
8562E/EC:
30 Hz–13.2 GHz (dc coupled)
100 kHz–13.2 GHz (ac coupled)
8563E/EC:
9 kHz–26.5 GHz (dc coupled)
30 Hz–26.5 GHz (Option 006)
8564E/EC:
9 kHz–40 GHz (dc coupled)
30 Hz–40 GHz (Option 006)
8565E/EC:
9 kHz–50 GHz (dc coupled)
30 Hz–50 GHz (Option 006)
+30 dBm Max
±0.2 V dc Max (dc coupled)
±50 V dc Max (ac coupled)
+30 dBm Max
±0.2 V dc Max (dc coupled)
±50 V dc Max (ac coupled)
+30 dBm Max
±0.2 V dc Max (dc coupled)
±50 V dc Max (ac coupled)
+30 dBm Max
±0.2 V dc Max (dc coupled)
+30 dBm Max
±0.2 V dc Max (dc coupled)
+30 dBm Max
±0.2 V dc Max (dc coupled)
PROBE POWER —— +15 V, −12.6 V (150 mA max)
CAL OUTPUT 300 MHz −10 dBm
IF INPUT*
(forusewithexternal
mixers)
310.7 MHz 0 V dc Max
1ST LO
OUTPUT
3.00 GHz–6.81 GHz +16.5 dBm ±2.0 dB
+14.5 dBm ± 3.0 dB‡
RF OUT 50 Ω†
(tracking generator
output)
300 kHz–2.9 GHz −10 dBm to +1 dBm
* Not available with an 8560E/EC Option 002 or Option 327.
† Available only with an 8560E/EC Option 002.
‡ LO output of an 8560E/EC Option 002.
