To check a created signal
This section assumes you have created a signal as shown on the previous
page, have not changed any setup parameters, and have not preset the
instrument.
This task uses digital demodulation. If you want to perform this task using
video demodulation, choose video demodulation instead of digital
demodulation in step 4.
1. Connect the source output to the channel 1 input and play the signal through
the arbitrary source:
Press [
Source
], [
source on
], [
source type
], [
arbitrary
]. The default data register is
D1.
2. Select the optimum range:
Press [
Range
].
Press the down-arrow key until the Channel-1 Over and Half LEDs are on.
Press the up arrow key one press at a time until the Over LED turns off.
For additional details about selecting the optimum range, see online help
for the [
Range], [ch1 range] softkey.
3. Select the internal trigger and choose a 5 symbol delay to truncate invalid data
at the beginning of the record:
Press [
Trigger
], [
trigger type
], [
internal source
], [
Return
], [
ch1 delay
], 164, [
us
].
4. Select the correct demodulation parameters:
Press [
Instrument Mode
], [
Digital Demodulation] (with option AYH, press [Instrument Mode
],
[
demod type
], [
Digital Demodulation
], [
Return] ).
Press
[demodulation setup
].
Pre ss [
result length
], 230, [
sym
]
Press [
ref filter
], [
raised cosine
]
Press [
Return
], [
meas filter
], [
root raised cosine
].
5. View the created signal versus the reference:
Press [
Display
], [
2 grids
],
Press [
A
], [
Measurement Data
], [
IQ measured time
]
Press [
B
], [
Measurement Data
], [
IQ reference time
]
Creating User-defined Signals (Options AYA and AYH)
11 - 4
