To send GPIB commands to the analyzer
1. Confirm that the first four tasks in this chapter have been completed.
2. If you do not know the network address of your analyzer, press [
Local/Setup
],
[
LAN setup
], [
LAN port setup
], then write down the value displayed under [
IP address
].
3. On the computer, type: telnet <IP_address>
(where <IP_address> is the network address of your analyzer).
4. On the computer, type the GPIB command that you want to send to the
analyzer. For example, to query the analyzer for its center frequency, type:
FREQ:CENTER?
5. To end your telnet session, type <Ctrl><D>.
The computer you use to send GPIB commands to the analyzer must be
attached to the network and configured with software that supports the
TELNET protocol. For additional information about using telnet, refer to
the documentation that came with your TELNET software.
Telnet is available only in analyzers that have option UTH. To determine if
your analyzer has this option, see this task: “To determine if you have
options UTH and UG7.”
Using the LAN (Options UTH & UG7)
14 - 6
