HP/Agilent 71910A Configuration
The 71910A receiver contains all the Modular Measurement System (MMS)
components which make wideband vector signal analysis possible. Minimally,
Option 004 (Analog I/Q Outputs) must be ordered and, depending on the other
measurements you may want to make with the system, the MMS display
(70004A) may also be needed. A system without the MMS display would be
ordered as an 71910A with Option 004, Option 011 and Option 012. In this
configuration, the display is deleted, but the 70310A reference module is added
(see the following table).
An existing 71209A Option 001 spectrum analyzer can be upgraded to support
wideband vector signal measurements by ordering an 70911A IF module
(Option 098 or Option 099 firmware upgrade required). You may also need to
upgrade the power supply in the 70001A mainframe. The receiver firmware
personality must be installed to facilitate the wideband vector signal
measurements described in this paper.
Note For additional information on firmware installation and system configuration, refer
to the 71910A User’s Manual.
A number of other modules and options are available for the family of MMS
spectrum analyzers. For more information, refer to the 71910A Product Overview
(p/n 5963-0087E) and the HP/Agilent 70000 Modular Measurement System Catalog
(p/n 5965-2818E).
Extending Analysis to 26.5 GHz with 20 MHz Information Bandwidth
16 - 8
