Recommended Configuration
Agilent 89410A Vector Signal Analyzer
(must be firmware revision A.04.00 or greater)
Option AY7 Second 10 MHz input channel
Option AYA Vector Modulation Analysis
Option 1C2 Instrument BASIC (includes the example program described earlier in this chapter)
HP/Agilent 71910A Wideband Receiver
(must be instrument firmware revision 94120 (B.05.00) or greater;
70910A RF module must be installed)
Configurations With the 70004A Display
Option 004 Analog I/Q outputs
Configurations Without 70004A Display
Option 004 Analog I/Q outputs
Option 011 Single mainframe configuration (deletes 70004A, 70902A, 70903A, and 70310A)
Option 012 Adds 70310A reference module
Other Accessories
8120-1838 50 ohm BNC–BNC cable, 12" (two required)
8120-6269 50 ohm BMC–SMB cable, 24" (one required)
10833A GPIB cable, 1 meter (one required)
Extending Analysis to 26.5 GHz with 20 MHz Information Bandwidth
16 - 9
