To view a W-CDMA signal
All tasks in this chapter were created using a 3GPP 1999 forward-link
signal (option 080). The signal was generated with an HP/Agilent E4433
ESG Signal Generator at 5 MHz, –10 dBm, and using the channel
definitions shown below. If you are using a different W-CDMA signal
(i.e., trial 1998 forward-link signal (option B73) or ARIB 1.0-1.2 forward-link
signal (option B79)), the tasks in this chapter still apply . However, in the
next task (To demodulate a W-CDMA signal), make sure you set the
demodulation parameters to match your signal.
Note Older E4433 ESG Signal Generator’s may flip the frequency spectrum at 5 MHz.
If necessary, correct for this when you demodulate the signal in the next task
(To demodulate a W-CDMA signal) by pressing [
Instrument Mode], [demodulation setup],
[
freq spectrum mirror].
Channel Rate (kSym/s) Spread Code Power
PSCH N/A N/A – 15.01
SSCH N/A N/A – 15.01
CPICH 15 0 – 20.01
DPCH 30 10 – 16.01
DPCH 30 11 – 16.01
DPCH 30 12 – 16.01
DPCH 120 8 – 9.01
DPCH 120 9 – 10.01
DPCH 120 10 – 11.01
DPCH 60 32 – 12.01
DPCH 60 33 – 12.01
DPCH 60 34 – 12.01
DPCH 60 35 – 12.01
DPCH 480 6 – 4.45
The following steps show you how to view your W-CDMA signal in the
Vector instrument mode to verify that the signal is present and that the
analyzer’s center frequency, span, and input range are set correctly.
Using Wideband CDMA (Options B73, B79, and 080)
13 - 2
