To recall waterfall and spectrogram displays
This procedure shows you how to recall waterfall and spectrogram
displays. See the previous procedure for instructions on saving waterfall
and spectrogram displays.
1. Activate the trace where you want the waterfall or spectrogram display. For
example, if you want to display a waterfall display in trace A, press [A].
2. Turn on the waterfall or spectrogram display.
Press [
Display
][
waterfall setup
][
waterfall on
].
OR
Press [
Display
][spectrogram setup][
spectrogram on].
3. If the trace buffer is in a file, recall the trace buffer from the file into a data
register (if the trace buffer is in a data register, skip this step):
Press [
Save/Recall
], [
recall more
], [
recall trace buffer
].
Cho ose a file and data register.
4. Display the data register:
Press [
Measurement Data
], [
data reg
]
Choose the desired data register.
Any trace buffer may be recalled as either a spectrogram or a waterfall,
regardless of which display was selected at the time the buffer was stored.
If the data register contains only one trace, then the waterfall or
spectrogram only displays the single scan.
Using Waterfall and Spectrogram Displays (Opt. AYB)
7 - 16
