Analyzing Digitally

Demodulated Signals

(Options AYA and AYH)

This chapter shows you how to analyze signals demodulated with Digital

Demodulation or with Video Demodulation. The tasks in this chapter use

digital demodulation, but the same steps apply to video demodulation. You

will learn how to select measurement data and compatible data formats,

use polar markers, examine symbol tables, display state definitions, and

examine errors.
